Package
R6/P600
Pppm@ 10/1000μs (W)
5000
VRWM Max. (V)
18
VBR@IT Min. (V)
20
VBR@IT Max. (V)
22.1
IT (mA)
1
VC@IPP Max. (V)
29.2
IPP@Max 10/1000μs (A)
171.23
IR@VRWM Max. (uA)
5
AEC-Q101
NO
5KP Series.pdf
