Package
R6/P600
Pppm@ 10/1000μs (W)
5000
VRWM Max. (V)
26
VBR@IT Min. (V)
28.9
VBR@IT Max. (V)
31.9
IT (mA)
1
VC@IPP Max. (V)
42.1
IPP@Max 10/1000μs (A)
118.76
IR@VRWM Max. (uA)
5
AEC-Q101
NO
5KP Series.pdf
