Package | disc 20mm |
Maximum Allowable Voltage Vac(V) | 14 |
Maximum Allowable Voltage Vdc(V) | 18 |
Varistor Voltage @1mA (V) | 22(19.8-24.2) |
Max Peak Current@ 8/20µs | 2000 |
Number of lighting @Max Peak Current 8/20µs | 1 |
Max Clamping Voltage@Ip Vc(V) | 43@20A |
Maximum Energy (10/1000µs) （J） | 7.4 |
20D Series.pdf
