封裝類型 | disc 25mm |
Maximum Allowable Voltage Vac(V) | 130 |
Maximum Allowable Voltage Vdc(V) | 170 |
Varistor Voltage @1mA (V) | 200(185-225) |
Max Peak Current@ 8/20µs | 20000 |
Number of lighting @Max Peak Current 8/20µs | 1 |
Max Clamping Voltage@Ip Vc(V) | 340@150A |
Maximum Energy (10/1000µs) （J） | 228 |
25D Series.pdf
