Package | square 34mm |
Maximum Allowable Voltage Vac(V) | 680 |
Maximum Allowable Voltage Vdc(V) | 895 |
Varistor Voltage @1mA (V) | 1100(990-1210) |
Max Peak Current@ 8/20µs | 40000 |
Number of lighting @Max Peak Current 8/20µs | 1 |
Max Clamping Voltage@Ip Vc(V) | 1815@300A |
Maximum Energy (10/1000µs) （J） | 1250 |
34S Series.pdf
